防撞緩沖車是一款能有效保障各種道路工程施工及道路管理活動區域內作業人員和設施安全,并能有效減輕碰撞車輛及其車上人員傷害程度的專用裝備。該裝備能通過特制的可動態顯示的高亮LED顯示屏主動引導過往車輛進行安全避行,通過裝配在卡車尾部的碰撞緩沖保護裝置能最大限度地保護撞擊車輛及車內人員的生命安全。
Configuration advantages and features
Single-stage collision energy absorbing device: The outer shell of the anti-collision buffer device is made of special lightweight materials, filled with plastic energy-absorbing materials in the middle, and the connecting body is a single-stage four curved tubes. When a collision occurs, the single-stage curved tube will absorb the impact energy through force deformation (the curved tube bends inward) at first. When the energy exceeds the deformation rate of the curved tube, the plastic deformation of the anti-collision cushion will continue to absorb the impact. The remaining energy of, to maximize the absorption of collision energy;
Easy-to-operate loading device: the main structure of the boom frame, through the 90-degree slewing mechanism to complete the two-stage boom telescopic, lifting and folding; through the four-point support for the body legs, further enhance the stability of on-site parking; By automatically flipping the cushion at 90 degrees, the preparation of the job site and the transfer after the job can be completed quickly;
Suitable for common-grade roads: The chassis of the mini-transporter is equipped with a strong anti-collision buffer structure, which is suitable for the daily management of the local common-grade county and town roads or urban roads with low speed.
High-brightness LED screen traffic guidance: Equipped with high-brightness lamp panel LED warning screen and high-reflective traffic signs, actively guiding passing vehicles safely, minimizing the impact of construction on road traffic, and effectively preventing traffic accidents.
Unique anti-corrosion and anti-rust performance: The whole truck adopts high-grade electrophoretic coating or compound electroplating treatment, with excellent anti-corrosion and anti-rust performance, without fear of various outdoor environments.
Item | Specification |
Anti-collision buffer device | 2030X790X1780mm |
Cushion Weight | 84kg |
Buffer Level | 2000kg-70km/h |
Buffer Structure Length | 2030mm |
Overall dimensions (LxWxH) | 5980X2030X2730mm |
Truck chassis parameters | Huanghai brand DD1032HE multi-purpose truck chassis |
Total weight | 3335kg |
Equipment weight | 1670kg |
Max. Speed | 140km/h |
Fuel type | Gasoline |
Power | 160 kw |
Overall dimensions (LxWxH) | 5375X1840X1940mm |
